GIGANET GN-UIC60L 6kVA/4.8kW Three Phase Online UPS
True online double conversion design
Build-in input and output transformer with strong galvanic isolation
Wide input range, avoid frequently transfer to battery mode, prolong the battery lifetime
With parallel function, flexibly response to the expansion and redundancy requirement
Intelligent battery management technology, fully protect battery
Battery cold start function
Comprehensive and reliable protection
GIGANET GN-UIC60L 6kVA/4.8kW Three Phase Online UPS
The GIGANET GN-UIC60L is a compact but powerful 6 kVA / 4.8 kW three phase online UPS engineered to deliver clean, reliable power for small to medium scale installations. With true double conversion technology, it continuously conditions incoming power and delivers a stable, pure sine wave output — safeguarding sensitive and mission critical equipment from power outages, surges, brownouts, spikes, and fluctuations.
Features |
| True online double conversion design |
| Build-in input and output transformer with strong galvanic isolation |
| Wide input range, avoid frequently transfer to battery mode, prolong the battery lifetime |
| With parallel function, flexibly response to the expansion and redun- dancy requirement |
| Intelligent battery management technology, fully protect battery |
| Battery cold start function |
| Comprehensive and reliable protection |
Specifications
| Model | GN-UIC60L | GN-UIC80L | GN-UIC100L | GN-UIC150L | GN-UIC200L | GN-UIC300L | GN-UIC400L |
| Capacity VA/Watts | 6kVA/4.8kW | 8kVA/6.4kW | 10kVA/8kW | 15kVA/12kW | 20kVA/16kW | 30kVA/24kW | 40kVA/32kW |
| INPUT | |||||||
| Operating Voltage Range | 380Vac(±20%), (3Ph+N+PE) | ||||||
| Operating Frequency Range | 50/60Hz (±5%) | ||||||
| Power Factor | ＞0.97 (with filter) | ||||||
| Max.Input Current(A) | 14 | 18 | 23 | 34 | 45 | 68 | 90 |
| OUTPUT | |||||||
| Output Voltage | 220Vac(1±1%) | ||||||
| Output frequency | 50/60Hz(1±1%) | ||||||
| Crest factor | 3:1(max) | ||||||
| Efficiency | 6~8KVA: 85% online 10~40KVA: 90% online | ||||||
| Harmonic Distortion (THDv) | ＜1.5% with linear load | ||||||
| BATTERY | |||||||
| Battery voltage | 192Vdc | 240Vdc | |||||
| SYSTEM FEATURES | |||||||
| Transfer time | Utility Battery : Oms | ||||||
| Overload | Load≤125%/ 1min; ≤150% /200ms,to Bypass | ||||||
| LED display | Battery low, Mains status, Inverter, Bypass, UPS failure, Overload | ||||||
| LCD display | I/O voltage, Frequency, Battery voltage, Load percentage,Internal temperature | ||||||
| Communication Interface | RS232, SNMP (optional), Dry contact,RS485 | ||||||
| PHYSICAL | |||||||
| Dimension W×D×H (mm) | 305*585*864 | 409*798**1044 | 555*741*1200 | 600*800*1200 | |||
| Net Weight（48V/192V）(kg) | 100 | 110 | 120 | 145 | 155 | 255 | 336 |
| ENVIRONMENT | |||||||
| Operating Temperature | 0~40°C | ||||||
| Storage Temperature | -25℃～55℃ | ||||||
| Humidity Range | 0~95% (Non-condensing) | ||||||
| Altitude | <1500m | ||||||
| Noise level | ＜55dB | ||||||
| STANDARDS | |||||||
| Safety | IEC/EN62040-1 ；IEC/EN60950-1 | ||||||
| EMC | IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8 | ||||||
