Grandstream GWN7702P 16-port Unmanaged Gigabit Switch

Original price was: KSh 20,000.00.Current price is: KSh 19,000.00. excl. VAT

8× port PoE+ output.
Green tech reduces power use.
LED Indicators for Link, Activity, Speed, and Power.
Auto MDI/MDIX for all ports.
Storm Control (fixed to 100Mbps) for traffic monitoring.
QoS: Supports Default Strict Priority (when present).

SKU: HB41960 Categories: Grandstream Store Kenya, Grandstream Switches Brand: Grandstream

Description
Reviews (0)

Grandstream GWN7702P 16-port Unmanaged Gigabit Switch

The Grandstream GWN7702P is a robust unmanaged Gigabit Ethernet switch geared for environments where both high port density and Power over Ethernet (PoE) support are required. With 16 RJ-45 Gigabit ports—half of which support PoE+—the GWN7702P enables seamless power and data delivery to devices like IP cameras, wireless access points, and VoIP phones, without needing separate power injectors.

As an unmanaged switch, it offers plug-and-play deployment with no configuration overhead, while built-in “green” features help reduce energy consumption. Its sturdy design supports desktop or wall mounting, making it suited for wiring closets, network racks, or office deployments.

Grandstream GWN7702P Technical Specification

	GWN7702	GWN7702P	GWN7703
Gigabit Ports	16	16	24
PoE Ports	N/A	8	N/A
Enclosure	Metal
Mounting	Desktop/Rack-Mount
Network Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p
PoE Standards	/	IEEE 802.3af, IEEE 802.3at	/
Port Feature	16/24× 10/100/1000Mbps RJ45 Ports AUTO NegotiationAUTO MDI/MDIX
Network Media	1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex
PoE Configuration	/	• 1~8 Ports 802.3 af/at compliant• Up to 30 W on Each Port, Total 138W Power Budget;• Overload to cut off the lowest- s priority port. • Priority: Port 1 to Port 8	/
LED Indicators	Per port: Link/Activity Green Per device: Power Green	Per port: Link/Activity – Green Per port: PoE output – Yellow Per device: Power Green	Per port: Link/Activity Green Per device: Power Green
Mac Address Table	8K
Switching Capacity	32Gbps	32Gbps	48Gbps
Jumbo Frame	10KB
Advanced Features	Mac Address Auto-Learning And Auto-Aging IEEE 802.3x Flow ControlHalf duplex backpressure
Power Adapter	Internal 100-240V AC, 50/60Hz,18W	Internal 100-240V AC, 50/60Hz,150W	Internal 100-240V AC, 50/60Hz,18W
Max Power Consumptionby Base System	8W@220V/50Hz	10.1W@220V/50Hz(excluding PoE output power)	13W@220V/50Hz
Environmental	Operating Temperature: 0 to 40 °C (32 to 104 °F)Storage Temperature: -20 to 60 °C (-4 to 140 °F)Operating Humidity: 10% to 90% Non-condensing Storage Humidity: 10% to 90% Non-condensing
Dimensions (L x W x H)	Unit: 280 x 180 x 44mm;Package: 366 x 211 x 53mm
Weight	Unit: 1.23KGEntire Package: 1.83KG	Unit: 1.58KGEntire Package: 2.18KG	Unit: 1.35KGEntire Package: 1.95KG
Package	1x Switch, 1x 1.2m AC Cable, Rack-mounting Standard Brackets, 4x Rubber Feet, 1x QIG
Compliance	FCC, CE, RCM, IC, UKCA
