Grandstream GWN7831 Layer 3 Aggregation Managed Switch

The GWN7831 is a Layer 3 aggregation managed switch that allows medium-to-large enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable. It provides 4 combo ports, 24 SFP ports and 4 SFP+ ports with a maximum switching capacity of 128Gbps.

It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP/MLD Snooping for network performance optimization, and comprehensive security capabilities against potential attacks. GWN7831 can be managed in a number of ways, including the local Web user interface of the GWN7831 switch and CLI, the command-line interface.

And also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform. With complete end-to-end quality of service and flexible security settings, the GWN7831 is the best value enterprise-grade managed switch for medium-to-large businesses.

Grandstream GWN7831 Technical Specifications

Network Protocol

• IPv4
• IPv6
• IEEE 802.3
• IEEE 802.3i
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3z
• IEEE 802.3ae
• IEEE 802.3az
• IEEE 802.3ad
• IEEE 802.3x
• IEEE 802.1p
• IEEE 802.1Q
• IEEE 802.3AB
• IEEE 802.1p
• IEEE 802.1D
• IEEE 802.1s
• IEEE 802.1w
• IEEE 802.1x

Gigabit Ethernet Ports

• 4x combo

Gigabit SFP Ports

• 24

Gigabit SFP+ Ports

• 4

Note: Support DAC Cable and must be ≤ 5m

Maximum no. of Supported Modules

• SM-1G: 24
• MM-1G: 24
• RJ45-1G: 12
• SM-10G: 4
• MM-10G: 4
• RJ45-10G: 2

Note: RJ45-1G, RJ45-10G modules must be interval inserted

Console

• 1

Integrated Power Supply

• 60W

External Redundant Power Supply (RPS)

• 12V/60W

Auxiliary Ports

• 1x Reset Pinhole

Forwarding Mode

• Store-and-forward

Total non-blocking throughput

• 64Gbps

Switching Capability

• 128Gbps

Forwarding Rate

• 95.232Mpps

Packet Buffer

• 12Mb

Network Latency

• <4µs

Switching

• 16K MAC addresses, including static, dynamic and filtering MAC address
• 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
• VLAN virtual interface
• GVRP(pending)
• 14 link aggregation
• Spanning tree, 32 instances for STP/RSTP/MSTP

Routing

• Static routing
• Dynamic routing, including:
• RIP
• RIPng
• OSPF
• OSPFv3
• Policy routing (pending)

Multicast

• IGMP Snooping with IGMPv2 and IGMPv3
• MLD Snooping with MLDv1 and MLDv2
• MVR (pending)

QoS/ACL

• Port priority
• Priority mapping
• Queue scheduling, including:
  • SP
  • WRR
  • WFQ
  • SP-WRR
  • SP-WFQ
• Traffic shaping
• Rate limit
• 2K ACL for Ethernet, IPv4, and IPv6

DHCP

• DHCP server
• DHCP relay
• Option 82, 60, 160, and 43

Maintenance

• CPU and memory monitoring
• Fault detection and alarm for power supply and fan
• SNMP
• RMON
• LLDP&LLDP-MED
• Backup and restore
• Syslog
• Diagnostics including:
  • Ping
  • Traceroute
  • Port mirroring
  • UDLD (TBD)
  • Copper test

Security

• User hierarchical management and password protection
• HTTPS, SSH, Telnet
• 802.1X authentication
• AAA authentication including RADIUS and TACACS+
• Storm control
• Port isolation
• Port security
• Sticky MAC
• Filtering MAC address
• IP source guard
• DoS attack prevention
• ARP inspection
• DHCP Snooping
• Loop protection including:
  • BPDU protection
  • Root protection (pending)
  • Loopback protection (pending)
• Kensington Security Slot (Kensington Lock) support

Mounting

• Desktop
• Wall-Mount
• Rack-Mount (rack-mounting kits included)

System LEDs

• 1x tri-color LED for device tracking and status indication

Power Supply LEDs

• 2x bi-color LEDs for per power supply PWR&RPS

Data Transferring LEDs

• 12x green-color LEDs

Fan

• 2

Environmental

• Operation: 0°C to 45°C, humidity 10% to 90% RH (Non-condensing)
• Storage: -10°C to 60°C, humidity: 10% to 90% RH (Non-condensing)

Dimensions

• 440mm(L) x200mm(W) x44mm(H)

Unit Weight

• 3.15Kg

Package Content

• 1x Switch
• 1x 1.2m (10A) AC Cable
• 1x 25cm Ground Cable
• 4x Rubber Footpads
• 1x Power Cord Anti-Trip
• 2x Rack-Mounting Kits
• 8x Screws (KM 3*6)
• 1x Quick Installation Guide
• 1x Console Cable (Optional)
• 1x RPS, External Redundant Power Supply(Optional)

Compliance

• FCC
• CE
• RCM
• IC
• UKCA
