Specification

Camera

Image Sensor

5 MP CMOS image sensor

Max. Resolution

2560 (H) × 1944 (V)

Min. Illumination

Color: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR

Shutter Time

PAL: 1/25 s to 1/50, 000 s

NTSC: 1/30 s to 1/50, 000 s

Day & Night

ICR

Angle Adjustment

Pan: 0 to 360°, Tilt: 0 to 90°, Rotation 0 to 360°

Signal System

PAL/NTSC

Lens

Lens Type

2.4 mm, 2.8 mm, 3.6 mm, 6 mm fixed lens

Focal Length & FOV

2.4 mm, horizontal FOV: 103°, vertical FOV: 81°, diagonal FOV: 142°

2.8 mm, horizontal FOV: 86°, vertical FOV: 63°, diagonal FOV: 120°

3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV: 112°

6 mm, horizontal FOV: 55°, vertical FOV: 40°, diagonal FOV: 70°

Lens Mount

M12


Image Parameters Switch

STD/HIGH-SAT

Image Settings

Brightness, Sharpness, Mirror, Smart IR

Frame Rate

TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps AHD: 5M@20fps, 4M@30fps, 4M@25fps

CVI: 4M@30fps, 4M@25fps

CVBS: PAL/NTSC

Day/Night Mode

Auto/Color/BW (Black and White)

Wide Dynamic Range (WDR)

Digital WDR

Image Enhancement

BLC, HLC

White Balance

ATW/MANUAL

AGC

Support

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

General

Material

Plastic

Dimension

60.9 mm × 57.9 mm × 138.8 mm (2.39″ × 2.28″ × 5.47″)

Weight

Approx. 147 g (0.32 lb.)

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication

HIKVISION-C

Language

English

Power Supply

12 VDC ±25%

Consumption

Max. 4.3 W

IR Range

Up to 25 m

Approval

Protection

IP67
