Hikvision DS-2DT6223-AELY Dark Fighter Series 2MP Outdoor Anti-Corrosion PTZ Network Dome Camera description

Overview

The Hikvision DS-2DT6223-AELY Dark Fighter Series 2MP Outdoor Anti-Corrosion PTZ Network Dome Camera is a high-performance surveillance solution designed for demanding outdoor environments. With its advanced features and robust construction, it offers exceptional security and monitoring capabilities.

About this item

6-inch 32x Anti-corrosion Network Speed Dome

• 1/1.8″ Progressive Scan CMOS
• Up to 1920 × 1080 resolution
• 32 × optical zoom, 16 × digital zoom
• Min. Illumination: Color: 0.002 Lux @(F1.5, AGC ON),B/W: 0.0002 Lux @(F1.5, AGC ON)
• 140dB WDR, 3D DNR, HLC
• 24 VAC Hi-PoE
• Support H.265+/H.265 video compression
• Support Rapid focus
• IK10, IP67
• Anti-Corrosion

Specifications

LensFOV

• 59.8° to 3.0° (Wide-Tele)
• Zoom SpeedApprox. 4.4 s (Optical Wide-Tele)
• Working Distance10 mm to 1500 mm (wide-tele)
• Aperture RangeF1.5 to F3.4
• Focal Length5.9 to 135.7 mm, 23× optical zoom


• Sub-Stream50Hz: 25fps (704×576, 352×288, 176×144); 60Hz: 30fps(704×480, 352×240, 176×120)
• Max. Resolution1920 × 1080
• Main Stream50Hz: 25fps (1920×1080, 1280×960, 1280×720); 60Hz: 30fps(1920×1080, 1280×960, 1280×720)
• Third Stream

  50Hz: 25fps (1920×1080, 1280×960, 1280×720, 704×576, 352×288, 176×144)

  60Hz: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 352×240, 176×120)

Compression Standard

• SVCYes

Camera Module

• Image Sensor1/1.8″ progressive scan CMOS
• White BalanceAuto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
• Shutter Time1/1 s to 1/30,000 s
• Day & NightIR Cut Filter
• Digital Zoom16×
• Privacy Mask24 programmable privacy masks; optional multiple colors and mosaics
• Focus ModeAuto/Semi-automatic/Manual
• WDR120 dB
• Rapid FocusNo

PTZ

• Movement Range (Pan)360° endless
• Pan SpeedConfigurable, from 0.1°/s to 300°/s, preset speed: 540°/s
• Movement Range (Tilt)From -10° to 90°
• Tilt SpeedConfigurable, from 0.1°/s to 240°/s, Preset Speed: 400°/s
• Proportional ZoomYes
• Presets300
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 patterns, with the recording time not less than 10 minutes per pattern
• Power-Off MemoryYes
• Park ActionPreset/Patrol/Pattern/Auto scan/Tilt scan/Random scan/Frame scan/Panorama scan
• Scheduled TaskPreset/Patrol/Pattern/Auto scan/Tilt scan/Random scan/Frame scan/Panorama scan/Dome reboot/Dome adjust/Aux output
