Hikvsion DS-TPE104(2T)-Special S Access Control Terminal
The Hikvision DS-TPE104(2T)-Special S is a high-performance access control terminal designed for secure and flexible entry management in various environments.
Key Features:
-
Biometric Authentication: Supports facial recognition, fingerprint, and card-based access for versatile and secure user identification.
-
Enhanced Processing: Equipped with a high-performance processor to deliver fast response times and smooth operation.
-
High-Capacity Storage: Can store up to 10,000 users and up to 200,000 event records.
-
Durable Design: Designed to withstand harsh environments with a rugged casing and stable performance under extreme conditions.
-
Flexible Integration: Easily integrates with Hikvision’s access control systems, time attendance, and third-party platforms.
-
Loop Detection Compatibility: Supports vehicle loop detection for specialized vehicle access scenarios.
-
User-Friendly Interface: Features a clear display and intuitive controls for ease of use by staff and visitors.
Specification
| Terminal | |
| CPU | Apollo Lake Platform Processor; 1.5 GHz |
| Memory | 4 GB |
| Storage | 1 x 3.5″ Surveillance-Level Hard Disk (OptionalCapacity: 1T/2T/4T) |
| Interface | |
| Indicator | 4 Indicators (1 x System Indicator, 1 x Hard Disk Status Indicator, 1 x Power Indicator, 1 x AlarmIndicator) |
| Audio | 1-ch Audio Input (MIC IN); 1-ch Audio Output(AUDIO OUT) |
| Video Output | 1 x HDMI, 1 x VGA |
| Alarm Input | 4-ch Alarm Input (ALARM IN), Voltage Range: 0 V to60 V |
| Alarm Output | 4-ch Alarm Output (ALARM OUT), Voltage Range: 0V to 60 V |
| RS-232 | RS-232 Interface |
| RS-485 | 2 x RS-485 Interface |
| USB | 4 x USB 3.0 Interface |
| Network Interface | 5 x 100 Mpbs/1000 Mpbs Self-Adaptive Interface, supporting connecting with switch; 1 x Independent 100 Mpbs/1000 Mpbs Self-AdaptiveInterface, supporting network isolation |
| Bracket | |
| Material | Black Aluminum Material |
| General | |
| Working Temperature and Humidity | -20 °C to 70 °C (-4 °F to 158 °F); 10 % to 95% (NoCondensation) |
| Power Supply | 12V DC /5A |
| Power Consumption | Max.: 50 W Average: 25 W |
| Dimensions | 245 × 170 × 65 mm (9.65 × 6.69 × 2.56 inch) |
| Weight | 2 kg (4.4 lb.) |
| Weight (with Package) | 2.5 kg (5.5 lb.) |
| Dimensions (with Package) | 450 × 240 × 105 mm (17.7 × 9.45 × 4.1 inch) |
| Material | Black Aluminum Material |
