Jakemy JM-9205A Digital Multimeter
The Jakemy JM-9205A Digital Multimeter is an easy-to-use electronic measuring instrument that features a large display screen, auto-zero function, adjustable holder and display screen, 32 kinds of adjustable independent testing range and auto power off.
This multimeter supports measurements such as DC and AC voltage, current, resistance, and continuity. It also includes basic safety protection to reduce the risk of damage during use. The durable casing allows it to handle regular fieldwork, while the simple dial control makes operation straightforward.
specifications:
- DC voltage measurement range of 200mV to 1000V, with an accuracy ± (0.5 Percent + 1)
- AC voltage measurement range from 200mV up to 750V, accuracy ± (0.8 Percent +3)
- DC current measurement scale is 20mA-20A, accuracy ± (0.8 Percent +1)
- Alternating current measurement scale from 20mA up to 20A, accuracy ± (1 Percent +3)
- Resistance measurement ability ranges from 200Ω up to 200MΩ, accuracy ± (2.5 Percent + 3)
- Capacitance measurement ranges from 2nF to 200μF
- Yes, it also includes a crystal diode test
- And you can rely on it for reliable diode testing
- Complete with a handy conduction buzzer
- Thoughtful feature of automatic shut down
- Powered by a 9-volt battery
- Maximum display count of 1999
- Compact size of 190 x 90 x 30mm
The package includes the JAKEMY JM-9205A Digital Multimeter itself, a set of test leads and a user manual for your convenience.
