Lightwave LW-PC-SCU-SCU-DX-MM-3M Fiber Patch Cord
Original price was: KSh 700.00.KSh 600.00Current price is: KSh 600.00. excl. VAT
- 3-metre fiber optic patch cord
- SC/UPC to SC/UPC duplex connectors
- OM2 50/125 µm multimode fiber
- LSZH (Low Smoke Zero Halogen) jacket
- Factory-polished connectors for low insertion loss
Lightwave LW-PC-SCU-SCU-DX-MM-3M Fiber Patch Cord
The Lightwave LW-PC-SCU-SCU-DX-MM-3M Fiber Patch Cord is a 3-metre multimode duplex fiber optic patch cable designed for high-speed optical networking in LANs, data centers, telecommunications rooms, and enterprise networks. It features SC/UPC connectors on both ends, OM2 50/125 µm multimode fiber, and a Low Smoke Zero Halogen (LSZH) jacket for enhanced safety in indoor installations. It is factory-terminated and tested to ensure reliable optical performance and low signal loss.
Technical Specifications
| Specification | Details |
|---|---|
| Model | LW-PC-SCU-SCU-DX-MM-3M |
| Fiber Type | OM2 Multimode (50/125 µm) |
| Connector A | SC/UPC Duplex |
| Connector B | SC/UPC Duplex |
| Cable Length | 3 metres |
| Jacket Material | LSZH |
| Jacket Colour | Aqua |
| Insertion Loss | ≤ 0.3 dB per connector |
| Return Loss | ≥ 20 dB |
| Operating Wavelength | 850 nm / 1300 nm |
| Supported Standards | 1000BASE-SX, Short-distance 10G Ethernet |
| Operating Temperature | -20°C to +70°C |
| Compliance | IEC 60793-2-10, TIA/EIA 492AAAB, RoHS |
Lightwave Patch Cord Applications
- Data center interconnections
- Fiber patch panels
- Network switches and routers
- Server rooms
- Enterprise LANs
- Telecommunications equipment
- Optical distribution frames (ODFs)
