Ubiquiti UniFi UCG-Max Cloud Gateway Max

The Ubiquiti UniFi UCG‑Max Cloud Gateway Max is a compact, high-performance UniFi gateway designed for advanced home networks and small-to-medium businesses. It combines routing, security, and UniFi network management into one powerful device.

Ubiquiti UniFi Cloud Gateway Max Key Features

• Includes full UniFi application suite for device management
• Manages 30+ UniFi devices and 300+ clients
• 1.5 Gbps routing with IDS/IPS
• Multi-WAN load balancing
• 512 GB NVMe SSD storage for NVR
• 0.96″ LCM status display
• USB-C powered (adapter included)

Its compact form factor conceals a robust suite of security measures, including firewall capabilities and intrusion detection systems, fortifying your network against evolving threats. With the Multi-WAN UniFi Cloud Gateway, you can expect uncompromising performance and comprehensive security in a streamlined package, perfect for businesses of all sizes.

Ubiquiti UniFi Cloud Gateway Max – Technical Specification

Mechanical

• Dimensions: 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2″)
• Weight: 519 g (1.1 lb)
• Enclosure material: Polycarbonate

Hardware

• Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
• System memory: 4 GB DDR4
• On-board storage: 512 GB NVMe SSD
• Management interface: Ethernet, Bluetooth
• Networking interface:
  • LAN: (4) 1/2.5 GbE RJ45 ports
  • WAN: (1) 1/2.5 GbE RJ45 port
• IDS/IPS throughput: 1.5 Gbps*
  • *Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
• Power method: USB type C (5V DC/5A)
• Supported voltage range: 100–240V AC
• Max. power consumption: 16.1W
• LCM display: 0.96″ status display
• Button: Factory reset
• Ambient operating temperature: -10 to 40° C (14 to 104° F)
• Ambient operating humidity: 5 to 95% noncondensing
• Certifications: CE, FCC, IC

Gateway Features

• Performance:
  • Redundant WAN with failover and load balancing
  • WiFi QoS with UniFi APs
  • Application, domain, and country-based QoS
  • Application and device type identification
  • Additional internet failover with LTE Backup
  • Internet quality and outage reporting
• Next-generation security:
  • Application-aware firewall rules
  • Signature-based IPS/IDS threat detection
  • Content, country, domain, and ad filtering
  • VLAN/subnet-based traffic segmentation
  • Full stateful firewall
• Advanced networking:
  • License-free SD-WAN
  • WireGuard, L2TP and OpenVPN server
  • OpenVPN client
  • OpenVPN and IPsec site-to-site VPN
  • One-click Teleport and Identity VPN
  • Policy-based WAN and VPN routing
  • DHCP relay
  • Customizable DHCP server
  • IGMP proxy
  • IPv6 ISP support

LEDs

• Ethernet: Green: link/activity

Application Requirements

• Mobile app: UniFi iOS™ and Android™: Version 10.17.2 and later
